【CF雙氣動高真空角閥】參數規格： CF Pneumatically Actuated Angle Valve（With bellows,air to open,air to close）
|
Model No.
|
Flange type
|
A
|
B
|
C
|
|
AVB-CR16-P2
|
CR16
|
63.5
|
161.3
|
57.1
|
|
AVB-CR25-P2
|
CR25
|
52.1
|
157.2
|
57.1
|
|
AVB-CR35-P2
|
CR35
|
62.2
|
196.3
|
76.2
|
|
AVB-CR50-P2
|
CR50
|
88.3
|
291.1
|
88.9
|
|
AVB-CR63-P2
|
CR63
|
85.9
|
266.2
|
99.6
|
|
AVB-CR100-P2
|
CR100
|
118.4
|
391.9
|
114.1
|
CF Pneumatically Actuated Angle Valve（Without bellows,air to open,air to close）
|
Model No.
|
Flange type
|
A
|
B
|
C
|
|
AV-CR16-P2
|
CR16
|
63.5
|
161.3
|
57.1
|
|
AV-CR25-P2
|
CR25
|
52.1
|
157.2
|
57.1
|
|
AV-CR35-P2
|
CR35
|
62.2
|
196.3
|
76.2
|
|
AV-CR50-P2
|
CR50
|
88.3
|
291.1
|
88.9
|
|
AV-CR63-P2
|
CR63
|
85.9
|
266.2
|
99.6
|
|
AV-CR100-P2
|
CR100
|
118.4
|
391.9
|
114.1
|
【CF雙氣動高真空角閥】產品特點： 1.CF雙氣動高真空角閥和CF無氧銅墊片,CF真空法蘭配套使用
2.CF雙氣動高真空角閥和CF真空三通,四通,五通,六通,彎頭,CF真空波紋管,KF真空軟管,真空腔體配合使用
3.CF雙氣動高真空角閥不帶電磁感應和信號線,靠通氣開啟和關閉（air to open,air to close）
|
